Description
Take on the toughest wood splitting jobs with the YARDMAX 35-Ton Full-Beam Log Splitter, engineered for high-capacity, all-day performance. With a massive 35-ton splitting force, this heavy-duty gas log splitter features a patent-pending U-Beam structural design, which offers 50% more strength and rigidity than traditional I-beam models, ensuring durability and resistance to flex and fatigue over time.
Powered by a reliable 208cc Briggs & Stratton CR950 engine, this splitter delivers rugged, industrial-grade power, while the dual-mode horizontal and vertical operation provides flexibility when working with oversized or heavier logs. Built for both power and convenience, the YARDMAX splitter includes log cradles, a beam handle for easy mode switching, oversized hydraulic components for fast cycle time, and steel fenders—all built into a tow-ready frame with DOT-approved tires.
✅ Key Features
-
Heavy-Duty Splitting Power:
Delivers a forceful 35 tons of splitting force to handle large-diameter logs up to 26.5 inches long and 20 inches wide.
-
Stronger U-Beam Design:
Patent-pending U-Beam construction is significantly stronger than traditional I-beams, increasing durability and minimizing flex during operation.
-
Briggs & Stratton 208cc Engine:
Equipped with a dependable 4-cycle CR950 engine, offering 9.5 ft-lb of torque and consistent performance across seasons.
-
Quick Cycle Time:
Oversized hydraulic components produce one of the fastest cycle times in its class—just 16.5 seconds per split.
-
Dual Operation Modes:
Easily converts between horizontal and vertical configurations, giving you ergonomic flexibility based on log size and user preference.
-
Log Cradles & Table Compatibility:
Adjustable dual-position log cradles keep split logs in place, with an option to add mountable log tables for added support.
-
Integrated Hydraulic System:
Features an internal hydraulic oil filter mounted inside the reservoir to prevent damage from falling logs and eliminate operator interference.
-
Durable Construction & Transport-Ready:
Includes solid stamped steel fenders, 16-inch DOT-approved tires, and a robust frame designed for frequent towing and transport.
-
Easy Mode Switching & Jam Removal:
Built-in beam handle allows fast transitions between modes; log stripper on the hydraulic cylinder helps remove jammed logs safely.
📦 What’s Included
-
(1) YARDMAX 35-Ton Log Splitter
-
(1) Briggs & Stratton 208cc CR950 Engine (pre-installed)
-
(2) Adjustable Log Cradles
-
(2) 16-inch Pneumatic Transport Tires
-
(1) Beam Handle for Horizontal/Vertical Mode Switching
-
(1) Log Stripper
-
(1) User Manual
🔧 Hydraulic fluid not included. Recommended: 10W AW32, ASLE H-150, or ISO 32.
📊 Technical Specifications
| Specification |
Details |
| Brand |
YARDMAX |
| Model Number |
YU3666 |
| Power Type |
Gas-Powered |
| Engine Brand |
Briggs & Stratton CR950 |
| Engine Displacement |
208cc |
| Torque |
9.5 ft-lb |
| Fuel Tank Capacity |
0.8 Gallons |
| Horsepower |
Not listed (CR950 torque rated) |
| Start Type |
Recoil (Pull Start) |
| Log Splitting Force |
35 Tons |
| Cycle Time |
16.5 Seconds |
| Maximum Log Length |
26.5 inches |
| Maximum Log Diameter |
20 inches |
| Operational Orientation |
Horizontal & Vertical |
| Hydraulic Capacity |
6.2 Gallons |
| Recommended Hydraulic Oil |
10W AW32, ASLE H-150, ISO 32 |
| Hydraulic PSI (Max) |
Not rated (system designed for 35-ton force) |
| Tire Size |
16 inches, DOT-approved |
| Construction Material |
Heavy-Duty Steel |
| Log Splitter Features |
DOT Approved, Log Cradles, Steel Fenders |
| Product Dimensions (L x W x H) |
91.5 in. x 48 in. x 37 in. |
| Product Weight |
542.3 lbs |
| Amperage (Electric System) |
N/A – Gas Powered |
| Country of Origin |
Imported |
| CARB-Compliant |
Yes |
