Description
The Tarter 4 ft. Sub-Compact Landscape Rake is a rugged, versatile implement ideal for sub-compact and compact tractors. Designed to smooth, contour, and clear gravel, soil, and debris, this 48-inch landscape rake is the perfect solution for a variety of landscaping and maintenance tasks.
Equipped with 24 heat-treated steel C-tines spaced 1 inch apart, the rake easily gathers rocks, sticks, and other loose material without aggressively disturbing your soil. The curved tine design prevents deep gouging, making it ideal for prepping surfaces, clearing trails, or maintaining gravel driveways.
This landscape rake features a Category 1 hitch and fits tractors from 15 to 32 horsepower. With its 360° pivoting design and 5 forward / 5 reverse angle settings (up to 45° left or right), it can be positioned to direct debris exactly where you want it—whether pushing or pulling.
Optional wheel kit (sold separately) allows for consistent depth control and smoother operation over uneven terrain.
✅ Key Features
-
48 in. Working Width: Ideal for sub-compact tractors and small-to-medium property maintenance.
-
24 Curved Steel Tines: Designed to remove debris efficiently without disturbing soil excessively.
-
Adjustable Angle Settings: 5 forward and 5 reverse positions up to 45° left or right for custom debris placement.
-
Reversible Operation: Easily use in forward or reverse gear for added flexibility in various tasks.
-
Heavy-Duty Steel Frame: Built for long-lasting performance and resistance to wear and tear.
-
Optional Wheel Kit Compatibility: Helps maintain a consistent raking depth and improves maneuverability (sold separately).
-
Cat 1 3-Point Hitch: Fast and secure attachment to tractors with standard Category 1 connections.
-
Made in the USA: Quality engineering and durability from a trusted American manufacturer.
🔧 Specifications
| Attribute |
Details |
| Brand |
Tarter |
| Model Number |
LR104BL |
| Working Width |
48 in. |
| Hitch Type |
Category 1 |
| Minimum Tractor HP |
15 HP |
| Maximum Tractor HP |
32 HP |
| Number of Tines |
24 |
| Tine Material |
Heat-treated Steel |
| Tine Type |
Curved C-tines |
| Tine Diameter |
1 in. |
| Tine Length |
21 in. |
| Tine Spacing |
1 in. |
| Angle Adjustment |
5 forward / 5 reverse (up to 45° left or right) |
| Frame Material |
Heavy-duty Steel |
| Optional Accessories |
Wheel kit (sold separately) |
| Assembly Required |
No |
| Product Height |
34 in. |
| Product Length |
44 in. |
| Product Width |
48 in. |
| Product Weight |
175 lb. |
| Country of Origin |
Made in USA |
| Warranty |
Manufacturer Warranty |
🌿 Perfect For:
-
Smoothing and grading gravel or soil
-
Clearing rocks, sticks, and yard debris
-
Maintaining trails, arenas, or gravel driveways
-
Sub-compact tractors needing a high-performance yet lightweight rake
