Description
The SKIL SPT70V-11 16-5/16 in. Worm Drive Circular Saw is the largest and most powerful worm drive circular saw in the world—built for high-demand professionals tackling the most extreme framing, timber, and structural cutting tasks. With a massive 6-1/4 in. cutting depth, it effortlessly powers through 6x lumber, laminated beams (LVL), and thick stock in a single pass.
Built with all-magnesium construction, this saw reduces weight without sacrificing durability, and the brass worm drive gearing ensures long-term reliability and cutting consistency. The 15 Amp Dual-Field™ motor, designed specifically for saws, runs cooler under load and delivers relentless torque to power through the toughest materials.
Outfitted with a precision-machined die-cast footplate, electric brake, and a factory-mounted 16-5/16 in. carbide-tipped blade, the SPT70V-11 is jobsite-ready right out of the box. Whether you're cutting heavy timbers or making rough dimension cuts, this saw is built to dominate.
Key Features
-
Largest Worm Drive Circular Saw on the Market
Industry-leading 6-1/4 in. cut capacity allows for clean, one-pass cuts through 6x materials.
-
15 Amp Dual-Field™ Brushed Motor
Patented motor design provides increased cooling, extends tool life, and delivers consistent cutting power.
-
Die-Cast Magnesium Footplate
Maintains accurate, square cuts while withstanding jobsite abuse.
-
All-Magnesium Housing
Reduces weight while enhancing durability and heat dissipation.
-
Electric Blade Brake
Stops the blade quickly after the trigger is released, improving safety and jobsite efficiency.
-
Brass Worm Drive Gearing
Provides legendary torque and cutting performance with smooth, powerful drive mechanics.
-
Left-Side Blade Orientation
Offers enhanced visibility of the cut line for right-handed users.
-
Comes Ready to Use
Includes a 16-5/16 in. SKILSAW® carbide-tipped blade and multifunction wrench.
Technical Specifications
| Specification |
Details |
| Brand |
SKIL |
| Model |
SPT70V-11 |
| Tool Type |
Worm Drive Circular Saw |
| Power Source |
Corded Electric |
| Amperage |
15 Amps |
| Voltage |
120V |
| Blade Diameter |
16-5/16 in. |
| Arbor Size |
1 in. |
| Blade Location |
Left |
| No Load Speed |
2,500 RPM |
| Bevel Capacity |
0° – 45° |
| Maximum Cutting Depth at 90° |
6-1/4 in. |
| Maximum Cutting Depth at 45° |
4-5/16 in. |
| Electric Brake |
Yes |
| Depth Adjustment |
Yes |
| Laser Guide |
No |
| Spindle Lock |
Yes |
| Blade Change |
Keyed (Wrench Included) |
| Cord Length |
10 ft. |
| Tool Weight |
27.3 lbs |
| Motor Type |
Brushed (Dual-Field™) |
| Brushless Motor |
No |
| Corded or Cordless |
Corded |
| Certifications |
UL Listed |
| Kit or Tool Only |
Tool Only |
| Warranty |
1-Year Limited Tool Warranty |
What’s Included
-
(1) SKIL SPT70V-11 16-5/16 in. Worm Drive Circular Saw
-
(1) SKILSAW® 16-5/16 in. Carbide-Tipped Blade
-
(1) Saw Stand
-
(1) Multi-Function Wrench
-
(1) User Instruction Manual
