Description
The Rolair 5520K17A-0001 Air Compressor delivers powerful performance, superior air capacity, and jobsite durability in a rugged, wheeled design. Engineered with a 1.5 HP low-RPM motor and a 20-gallon ASME-certified horizontal tank, this unit provides 7.3 CFM at 90 PSI — making it ideal for demanding pneumatic tasks like running multiple framing, roofing, or trim guns simultaneously.
Perfectly suited for contractors, remodelers, and pros needing higher reserve air than twin-tank models, this compressor features a durable cast-iron two-cylinder pump, stainless steel reed valves, and automotive-style bearing inserts to extend pump life. Quiet operation, reliable cold starts, and industrial-grade componentry round out this heavy-duty, made-in-USA unit — designed to survive the harshest jobsite conditions.
🔧 Key Features
-
7.3 CFM @ 90 PSI
Delivers high airflow to operate multiple pneumatic tools with minimal downtime.
-
20-Gallon ASME-Certified Tank
Offers more than double the air reserve of standard twin-tank units for extended runtime.
-
Low RPM Pump & Motor
Quiet and efficient operation for reduced wear and longer service life.
-
Industrial Two-Cylinder Pump
Includes cast iron cylinders, oil sight glass, stainless steel reed valves, finned aftercooler, and oil drain extension.
-
Heavy-Duty Belt Guard
Two-piece 16-gauge steel guard improves cooling and protects moving parts.
-
Thermal Overload Protection
With manual reset to prevent motor damage from overheating.
-
Cold-Start Valve
Aids starting in low temperature environments.
-
Heavy-Duty Wheelbarrow Design
With large pneumatic tires and front handle for easier mobility across rugged terrain.
-
Not CARB-Compliant
Not rated for use in California.
📦 Includes
-
Rolair 5520K17A-0001 1.5 HP Air Compressor
-
Pressure regulator and dual gauges
-
Safety relief valve
-
Ball valve tank drains
-
Thermal overload protection
-
Cold-start valve
-
Factory-filled oil
📊 Technical Specifications
| Specification |
Details |
| Brand |
Rolair |
| Model Number |
5520K17A-0001 |
| Compressor Type |
Portable, Wheelbarrow Style |
| Pump Type |
Oil-Lubricated, Single Stage, Two Cylinder |
| Horsepower |
1.5 HP |
| Voltage |
115V |
| Amperage |
17.0 A |
| Max Pressure |
135 PSI |
| Air Delivery |
7.3 CFM @ 90 PSI |
| Tank Capacity |
20 Gallons (ASME-Certified) |
| Tank Configuration |
Horizontal, Single |
| Tank Material |
Steel |
| Operating Position |
Horizontal |
| Noise Level |
Low (RPM-Reduced for Quiet Operation) |
| Height |
34 in |
| Length |
72 in (6 ft) |
| Weight (Assembled) |
205 lbs |
| Shipping Weight |
205 lbs |
| Wheels |
Yes (3.5 in) |
| Handle Included |
Yes |
| UL Listed |
Yes |
| Country of Origin |
United States |
| UPC |
662865258752 |
| Warranty |
1-Year Limited |
