Description
The Remco 5500 Series 4.0 GPM Sprayer Pump is a top-tier, professional-grade pump designed for superior performance, long service life, and maximum efficiency in agricultural spraying applications. Engineered with durable components and backed by rigorous factory testing, this 12V DC diaphragm pump delivers reliable on-demand performance at 60 PSI and can withstand continuous-duty cycles in the harshest field conditions.
This pump is chemically compatible with most agricultural solutions including herbicides, fertilizers, and insecticides. With its sealed electric motor, self-priming capability up to 14 feet, and dry-run capability, the Remco 5500 Series is a rugged performer that delivers consistent flow and pressure even in demanding environments.
✅ Key Features
-
🚜 Professional-Grade Performance
Designed for continuous-duty spraying operations with durable components and efficient motor technology.
-
💧 4.0 GPM Flow Rate @ 60 PSI
High-volume delivery ideal for boom sprayers, spot sprayers, and multi-nozzle systems.
-
🔌 12V DC Sealed Motor
Built for harsh environments with sealed design for moisture and dust resistance.
-
🔁 Self-Priming & Run-Dry Safe
Priming height up to 14 ft. vertically. Pump is safe to run dry without damage.
-
🧪 Chemical Compatibility
Handles common agricultural chemicals such as herbicides, fertilizers, and insecticides.
-
🌡️ Heat-Resistant Design
Rated for maximum liquid temperature of 140°F and shell temperature up to 180°F.
-
🔌 Efficient Wiring
Includes 6 in. heavy-duty 14 AWG wire leads with SAE 2-pin connector for low operating temperatures and power efficiency.
-
🔧 Factory Tested & Quality Assured
Each unit is 100% factory tested for reliable performance right out of the box.
📐 Specifications
| Specification |
Details |
| Brand |
Remco |
| Model Number |
90-5516-1E1-82B-SB |
| Product Type |
Agricultural Diaphragm Sprayer Pump |
| Flow Rate |
4.0 GPM |
| Operating Pressure |
60 PSI (On-Demand) |
| Voltage |
12V DC |
| Motor Type |
Sealed Electric (Brush Motor) |
| Inlet/Outlet Size |
3/4 in. Quick Attach Ports |
| Included Fittings |
(1) 1/2 in. Hose Barb – Straight, (1) Elbow |
| Self-Priming Height |
Up to 14 ft. vertically |
| Dry Run Capability |
Yes |
| Liquid Compatibility |
Herbicides, Insecticides, Fertilizers |
| Max Liquid Temperature |
140°F (60°C) |
| Max Shell Temperature |
180°F (82°C) |
| Wire Leads |
6 in., 14 AWG with SAE 2-pin connector |
| Primary Material |
Polypropylene |
| Product Dimensions (L x W x H) |
10.8 in. x 6 in. x 5.3 in. |
| Product Weight |
6.6 lbs |
| Warranty |
1-Year Limited Manufacturer Warranty |
| Country of Origin |
United States |
📦 What’s Included
-
(1) Remco 5500 Series 4.0 GPM Pump
-
(1) 1/2 in. Hose Barb Fitting – Straight
-
(1) 1/2 in. Hose Barb Fitting – Elbow
