Description
Engineered for superior field coverage and efficiency, the FIMCO 300-Gallon 3-Point Broadcast Sprayer is a high-performance sprayer designed for use with Category 1, 2, or 3 tractors. Built for agricultural professionals and large-acreage property owners, this sprayer features a durable 300-gallon UV-resistant tank, Hypro 8-Roller Cast Iron Pump, and both broadcast and spot spray options to tackle a wide range of spraying tasks with precision.
At the core is a 2-nozzle broadcast spray system that delivers up to 34 feet of total swath coverage, ideal for spraying fertilizers, herbicides, insecticides, and other crop protection chemicals. The included 22-inch Pro Series Spray Wand offers pinpoint accuracy for spot treatments, with an impressive horizontal reach of up to 45 feet and vertical throw of 30 feet.
Designed for reliability, safety, and ease of use, this sprayer features an integrated sump for full drainage, independent nozzle control, and a robust powder-coated steel frame to handle the demands of tough agricultural work.
✅ Key Features:
-
300-Gallon Polyethylene Tank:
UV-stabilized, molded polymer tank with 8" wide-fill lid and built-in sump for easy cleaning and complete chemical drainage.
-
Broadcast Spraying Capability:
Two Hypro broadcast nozzles provide up to 34 feet of total spray swath, each with independent shutoff control for selective coverage.
-
Powerful Hypro 8-Roller Pump (Cast Iron):
PTO-driven pump delivers up to 22.5 GPM at 300 PSI, ensuring consistent high-pressure spray performance for large-scale jobs.
-
Pro Series 22" Spray Wand:
Includes locking handle and adjustable spray tip, allowing for stream-to-fan pattern control. Connects to 25 feet of reinforced 3/8" hose.
-
Built for Tractors:
Compatible with Category 1, 2, or 3 3-point hitch systems; heavy-duty powder-coated steel frame ensures long-lasting durability.
-
Versatile Application:
Perfect for use in pastures, crop rows, food plots, orchards, vineyards, parks, and roadways.
📊 Specifications:
| Attribute |
Details |
| Brand |
FIMCO |
| Manufacturer Part Number |
5303772 |
| Country of Origin |
Made in USA |
| Sprayer Type |
3-Point Hitch Mounted |
| Tank Capacity |
300 Gallons |
| Tank Material |
Polyethylene (UV-Stabilized) |
| Pump Type |
Hypro 8-Roller (Cast Iron) |
| Power Type |
PTO (12 Volt system listed in spec for wand use) |
| Maximum Flow Rate |
22.5 GPM |
| Maximum Operating Pressure |
300 PSI |
| Number of Nozzles |
2 Broadcast Nozzles + 1 Spot Spray Wand |
| Swath Width (Broadcast) |
34 ft. |
| Spray Wand |
22 in. Pro Series with Adjustable Tip |
| Maximum Horizontal Throw |
45 ft. (Spray Wand) |
| Maximum Vertical Throw |
30 ft. (Spray Wand) |
| Hose Length |
25 ft. |
| Hose Diameter |
3/8 in. |
| Mounting Type |
Pin - Compatible with Cat. 1, 2, 3 Hitches |
| Frame Construction |
Welded Powder-Coated Steel |
| Primary Color |
White |
| Product Dimensions (L×W×H) |
90 in. × 50 in. × 60 in. |
| Product Weight |
455 lb. |
| Recommended Chemicals |
Herbicides, Fertilizers, Insecticides, Fungicides, Pesticides, and Other Ag Solutions |
| Features |
Independent Broadcast Nozzles, Pro Wand, Chemical-Resistant |
| Warranty |
1-Year Consumer / 90-Day Commercial |
