Description
The Fimco 200-Gallon 3-Point Hitch Sprayer is a high-capacity, professional-grade solution built for precision liquid application across large agricultural areas. Designed for use with Category 1, 2, or 3 tractors, this sprayer is ideal for row crop spraying, pasture maintenance, and commercial applications.
Equipped with a Hypro 8-Roller Cast Iron Pump, this unit delivers a powerful 22.5 GPM flow rate and up to 300 PSI of spraying pressure, ensuring thorough and efficient chemical application. The FX4 folding boom features 12 TeeJet AIXR nozzles for a 20-foot spray swath, allowing for uniform and drift-reducing coverage. The boom is spring-loaded for smooth deployment and transport.
A Pro Series 22-inch spray wand provides additional flexibility, offering up to 45 feet of horizontal and 30 feet of vertical spray range—perfect for spot treatments and hard-to-reach areas.
Built on a welded powder-coated steel frame, and paired with a UV-resistant 200-gallon poly tank featuring a complete drainage sump and an easy-access 8-inch lid, this sprayer is engineered for durability, ease of use, and long-lasting performance.
Key Features:
-
High-Capacity Tank:
200-gallon molded polymer tank with UV stabilization and full-drain sump for efficient chemical use and easy cleanup.
-
Robust 8-Roller Pump:
Cast iron Hypro 8-roller pump delivers up to 22.5 GPM at 300 PSI, equipped with a quick-connect PTO coupler for easy tractor hookup.
-
FX4 12-Nozzle Boom:
Spring-loaded, welded steel boom with 12 TeeJet AIXR nozzles provides 20 feet of total spray coverage. Features air induction tips to reduce drift and no-drip check valves for clean starts and stops.
-
Pro Series Spray Wand:
22-inch high-pressure spray wand with a locking handle and adjustable brass tip. Achieves up to 45 ft. horizontal and 30 ft. vertical spray reach. Includes 25 feet of 3/8-inch hose for added flexibility.
-
Tractor Compatibility:
Compatible with Category 1, 2, and 3 3-point hitches, making it versatile for a wide range of small to midsize tractors.
-
Durable Frame:
Built on a powder-coated, welded steel frame for corrosion resistance and structural integrity in tough agricultural environments.
-
Precision Application:
TeeJet AIXR nozzles spray independently for efficient, controlled, and even chemical distribution.
Specifications:
| Attribute |
Details |
| Brand |
Fimco |
| Manufacturer Part Number |
5303767 |
| Country of Origin |
Made in USA |
| Sprayer Type |
3-Point Hitch Mounted |
| Tank Capacity |
200 Gallons |
| Tank Material |
UV-Stabilized Polyethylene |
| Pump Type |
Hypro 8-Roller Cast Iron |
| Pump Flow Rate |
22.5 GPM |
| Max Operating Pressure |
300 PSI |
| Boom Type |
FX4 Folding Steel Boom |
| Number of Nozzles |
12 TeeJet AIXR Nozzles |
| Spray Swath Width |
20 ft. |
| Spray Wand |
22 in. Pro Series with Adjustable Nozzle |
| Max Horizontal Spray |
45 ft. |
| Max Vertical Spray |
30 ft. |
| Hose Length |
25 ft. |
| Hose Diameter |
3/8 in. |
| Mounting Type |
Pin (Category 1, 2, 3 Hitch Compatible) |
| Frame Construction |
Welded Powder-Coated Steel |
| Power Source |
PTO (Pump-Driven) |
| Primary Color |
White |
| Product Dimensions (L×W×H) |
51 in. × 46 in. × 89 in. |
| Product Weight |
415 lb. |
| Compatible Chemicals |
Fertilizers, Herbicides, Pesticides, Fungicides, Insecticides |
| Warranty |
1-Year Consumer / 90-Day Commercial |
| Features |
Pro Wand, Adjustable Boom, Pressure Control |
