Description
The DEWALT DXCMV5048055 80-Gallon Two-Stage Air Compressor is engineered to meet the needs of serious professionals and demanding industrial environments. With its powerful 5 HP electric motor, rugged cast iron two-stage pump, and a high-capacity 80-gallon ASME tank, this stationary air compressor is ideal for powering multiple air tools simultaneously — ensuring efficiency, durability, and consistent performance.
This compressor delivers up to 175 PSI maximum pressure, making it suitable for high-demand applications such as automotive, metal fabrication, woodworking, and construction. Built for reliability and safety, it features an integrated TOPS (Thermal Overload Protection System) motor, precision-balanced flywheel, and splash lubrication for smooth operation and long-term durability.
🛠️ Key Features:
-
Powerful 5 HP Electric Motor:
Operates on 230V single-phase power and includes TOPS thermal overload protection, safeguarding the motor against voltage drops and overheating.
-
Durable Cast Iron Two-Stage Pump:
Engineered for long life with hardened steel disc valves, oversized taper roller bearings, splash-type lubrication, and a precision-balanced cast iron flywheel for reduced vibration.
-
High Air Output:
Provides 175 PSI maximum pressure, enabling the simultaneous operation of multiple air tools for faster task completion.
-
Integrated Control Panel:
Designed for user convenience with dual pressure gauges (tank and working pressure), airflow regulator, two quick-connect couplers, and a pressure relief valve — all within easy reach.
-
Pre-Filled with Synthetic Oil:
Comes ready for operation with high-performance synthetic blend compressor oil, minimizing wear during startup and extending component life.
-
80-Gallon Vertical ASME-Certified Tank:
Provides extended air storage for continuous use and features a vertical orientation to save floor space in your shop or workspace.
📋 Technical Specifications:
| Specification |
Details |
| Brand |
DEWALT |
| Model Number |
DXCMV5048055 |
| Horsepower |
5.0 HP |
| Voltage |
230V (Single Phase) |
| Amperage |
24.0 A |
| Compressor Pump Type |
Oil-Lubricated, Cast Iron, Two-Stage |
| Maximum Pressure |
175 PSI |
| Tank Capacity |
80 Gallons (ASME Certified) |
| Tank Orientation |
Vertical |
| Tank Material |
Steel |
| CFM Rating |
Approx. 15–16 CFM @ 100 PSI (not explicitly listed) |
| Motor Protection |
TOPS (Thermal Overload Protection System) |
| Control Panel |
Integrated with dual gauges, regulator, 2 quick connects |
| Pre-Oiled |
Yes (Synthetic Blend Oil) |
| Color |
DEWALT Yellow / Black |
| Certifications |
CSA Certified |
| Country of Origin |
United States |
| Height |
80 inches |
| Length |
34.75 inches |
| Package Depth |
35 inches |
| Weight (Assembled) |
475 lbs |
| Product Condition |
New |
| Warranty |
2-Year Limited Warranty |
| UL Listed |
No |
| ETL Listed |
No |
| UPC |
846212008638 |
| Proposition 65 Warning |
Yes (California Residents) |
| Wheeled |
No |
📦 What’s in the Box:
-
(1) DEWALT 5 HP 80-Gallon 2-Stage Air Compressor
-
(1) Pre-installed synthetic oil
-
(1) Integrated control panel
-
(1) User Manual
-
(1) Limited 2-Year Warranty Documentation
