Description
The DEWALT DXCM201 is a powerful 20-gallon, 200 PSI portable air compressor designed for high-efficiency air tool performance. Engineered with a durable oil-lubricated, belt-driven twin-cylinder pump, this compressor delivers 53% longer runtime compared to similar 155 PSI units. It’s the ideal solution for professionals tackling light automotive work, medium-duty metal fabrication, and agricultural equipment maintenance.
Operating at only 78 dBA, the DXCM201 ensures a quieter work environment without sacrificing performance. With 6.2 SCFM at 90 PSI, it powers a wide range of air tools including impact wrenches, sanders, and paint sprayers. The heavy-duty pneumatic wheels and horizontal tank design make it easy to move across jobsites, garages, or workshops.
🔧 Key Features
-
High-Capacity Airflow
Delivers 6.2 SCFM @ 90 PSI, supporting a larger selection of air tools with reduced downtime.
-
200 Max PSI Rating
Provides up to 53% longer air tool run time compared to 155 PSI compressors in the same size class.
-
Quiet Operation
Low 78 dBA noise level helps maintain a quieter, more comfortable work setting.
-
Heavy-Duty Twin-Cylinder Pump
Oil-lubricated and cast iron-constructed for enhanced durability and longevity.
-
Precision Components
Features automotive-style pistons, aluminum head and valve plate for superior heat dissipation, and a one-piece connecting rod for reduced vibration.
-
Optimized for Portability
Equipped with 10-inch pneumatic wheels and a robust horizontal tank for stable movement across rough surfaces.
-
High-Efficiency Flywheel
Aluminum flywheel improves airflow and reduces start-up amp draw.
-
Leak-Free Design
High-quality O-ring seals prevent oil leaks for cleaner operation.
📦 What's Included
-
DEWALT DXCM201 20-Gallon Portable Horizontal Air Compressor
-
High-flow regulator and coupler
-
Factory-filled synthetic compressor oil
-
Owner’s manual
📊 Technical Specifications
| Specification |
Details |
| Brand |
DEWALT |
| Model Number |
DXCM201 |
| Compressor Type |
Oil-Lubricated, Belt Drive |
| Design |
Portable, Horizontal |
| Horsepower |
2.0 HP |
| Tank Capacity |
20 Gallons |
| Max Pressure |
200 PSI |
| Air Delivery |
6.2 SCFM @ 90 PSI |
| Pump Design |
Twin-Cylinder, Cast Iron |
| Operating Noise Level |
78 dBA |
| Voltage |
120V (Single Phase) |
| Amperage |
15 A |
| Tank Material |
Steel |
| Tank Configuration |
Single Horizontal |
| Dimensions (L x H) |
33 in x 32 in |
| Package Dimensions |
37.25 in x 33.5 in |
| Assembled Weight |
137 lbs |
| Shipping Weight |
151 lbs |
| Wheels |
Yes – 10 in Pneumatic |
| Country of Origin |
USA |
| Certifications |
CSA Certified |
| Decibel Rating |
78 dBA |
| UL/ETL Listed |
UL: No / ETL: No |
| Warranty |
2-Year Limited |
| UPC |
846212077689 |
