Description
Product Overview
Experience exceptional performance and precision with the Cub Cadet Ultima ZT1-60, a 60-inch zero-turn riding lawn mower engineered for homeowners demanding commercial-grade quality. Powered by a 26 HP Kohler KT-Pro 7000 Series V-Twin OHV engine, this mower features dual hydrostatic transmissions, a rugged fabricated deck, and industry-leading comfort and control. Perfect for properties up to 10 acres, the ZT1-60 combines speed, durability, and cutting performance in one robust machine.
Key Features
-
Engine Power:
26 HP / 747cc Kohler KT-Pro 7000 Series V-Twin OHV engine for high torque, fuel efficiency, and smooth performance.
-
Deck System:
Heavy-duty 60-inch AeroForce™ fabricated cutting deck with reinforced leading edges and triple guard corrosion defense system (e-coat finish), backed by a limited lifetime warranty.
-
Cut Quality:
Three precision blades deliver a signature Cub Cadet cut with fewer clumps, finer clippings, and superior evenness.
-
Speed & Maneuverability:
Dual hydrostatic transmissions deliver up to 7 MPH forward and 3.5 MPH reverse ground speed with zero-turn capability for fast, tight trimming around obstacles.
-
Durable Frame:
2" x 2" tubular steel continuous frame with fully e-coated corrosion protection to withstand long-term wear.
-
Comfort & Control:
-
20-inch high-back seat with advanced polymer suspension.
-
3-way adjustable ergonomic lap bars with integrated parking brake.
-
Soft-touch hand grips and vibration-dampening floor mat.
-
Automotive-inspired comfort and adjustability.
-
Deck Height Adjustment:
Foot-operated deck lift and knob-style control offer 15 height positions from 1" to 4.5".
-
Precision Trimming:
Offset front casters align with blade path for precise edge cutting and optimized visibility.
-
Illuminated for Visibility:
Integrated dual LED headlights for low-light mowing conditions.
-
Maintenance Made Easy:
Open-frame design with a hinged/removable floor pan allows easy access to engine and deck.
-
Turf-Friendly Tires:
-
Front wheels: 11 in. x 6 in. -5 in. smooth tread, pivot 180° without turf damage.
-
Rear tires: 20 in. x 10 in. -8 in. Turf Master for excellent traction and stability.
-
Additional Conveniences:
Specifications
| Category |
Details |
| Engine Brand |
Kohler |
| Engine Model |
KT-Pro 7000 Series V-Twin OHV |
| Engine Displacement |
747cc |
| Horsepower |
26 HP |
| Fuel Type / Capacity |
Gasoline / 3.5 Gallons |
| Recommended Oil Type |
10W-30 |
| Transmission Type |
Dual Hydrostatic |
| Drive Type |
Rear Wheel Drive |
| Cutting Width |
60 in. |
| Deck Construction |
Fabricated Steel (AeroForce™) |
| Deck Height Positions |
15 Positions (1"–4.5") |
| Blade Engagement |
Electric PTO |
| Number of Blades |
3 |
| Front Tire Size |
11 in. x 6 in. – 5 in. |
| Rear Tire Size |
20 in. x 10 in. – 8 in. |
| Top Forward Speed |
7 MPH |
| Top Reverse Speed |
3.5 MPH |
| Turning Radius |
0 in. (True Zero-Turn) |
| Steering Type |
Lap Bar |
| Start Type |
Electric |
| Deck Lift System |
Foot Pedal with Dial Adjustment |
| Lighting |
Dual LED Headlights |
| Frame Material |
2" x 2" Tubular Steel (E-Coated) |
| Mower Yard Size Range |
More than 10 Acres |
| Terrain Capability |
Flat, Uneven, Most Terrains |
| Seat Type |
20 in. High-Back with Suspension System |
| Attachments Available |
Yes (Baggers, Mulch Kits, Carts, etc.) |
| Product Dimensions (L x W x H) |
82 in. x 67 in. x 35 in. |
| Product Weight |
605 lb. |
| Battery Voltage |
12V Starter Battery |
| Warranty |
3-Year Unlimited Hour Residential Warranty, Lifetime Frame & Deck Shell Warranty |
| Country of Origin |
Made in USA |
Manufacturer Part Number: 17AREAC5A10
Brand: Cub Cadet
Color: Yellow
Ships fully crated; some assembly required upon delivery.
