Description
ake on tough drilling and chiseling applications with the CRAFTSMAN V20™ 1 in. Cordless Rotary Hammer Drill. Designed with a high-performance brushless motor, this tool delivers extended runtime, enhanced durability, and efficient power output. With up to 2.0 joules of impact energy and 5,680 BPM, this rotary hammer is built to deliver fast and reliable results, even in dense materials like concrete or masonry.
Its compact, well-balanced design improves handling and makes it ideal for overhead and tight-space applications, while the lightweight structure helps reduce operator fatigue over prolonged use. The SDS-Plus chuck allows for quick bit changes and secure retention, enhancing your productivity on the jobsite.
Perfect for electricians, plumbers, and general contractors, the V20 Rotary Hammer Drill is a part of the CRAFTSMAN V20™ cordless system, delivering convenience, power, and compatibility across a wide range of tools.
🔧 Key Features
-
Brushless Motor: Offers longer runtime, increased efficiency, and extended tool life
-
2.0 Joules of Impact Energy: Drives high-performance drilling in concrete and masonry
-
High Impact Rate: Up to 5,680 blows per minute (BPM) for rapid chiseling and drilling
-
Maximum Speed: Delivers up to 1,500 RPM for fast drilling in various materials
-
Compact & Balanced Design: Lightweight at only 6.1 lbs, ideal for tight spaces and overhead use
-
Durable Mechanism: Built to withstand demanding jobsite conditions
-
SDS-Plus Chuck System: Enables fast bit changes and improved bit retention
-
Variable Speed Trigger: Allows control to match speed with application needs
-
Forward/Reverse Switch: Easily alternate between drilling and bit removal
-
Cordless Convenience: Compatible with all CRAFTSMAN V20™ lithium-ion batteries
Battery and charger sold separately.
📐 Technical Specifications
| Attribute |
Details |
| Brand |
CRAFTSMAN |
| Model Number |
CMCH233B |
| Power Source |
V20™ Lithium-Ion Battery (sold separately) |
| Tool Type |
Rotary Hammer Drill |
| Chuck Type |
SDS Plus |
| Chuck Size |
7/8 in. |
| Maximum Concrete Capacity |
1 in. |
| Impact Energy |
2.0 Joules |
| No Load Speed |
0–1,500 RPM |
| Blows per Minute (BPM) |
0–5,680 |
| Variable Speed |
Yes |
| Forward/Reverse Control |
Yes |
| Tool Length |
15-7/8 in. |
| Tool Weight |
6.1 lbs |
| Corded or Cordless |
Cordless |
| Motor Type |
Brushless |
| Keyless Chuck |
Yes |
| Kit or Tool Only |
Tool Only |
| Certifications |
None |
| Warranty |
3-Year Limited Warranty |
| Case Included |
No |
| UPC |
[Varies by retailer] |
📦 What’s Included
Battery and charger are not included and must be purchased separately.
✅ Ideal Applications
-
Anchoring and hole drilling in concrete and masonry
-
Chiseling tile, plaster, or light demolition
-
Drilling through brick, wood, and other common materials
-
Overhead drilling or confined workspaces
🔁 Returns & Warranty
